IP Camera BCS-V-EIP58VSR4-AI2 - 8Mpx, 4K UHD 2.8 ... 12mm BCS View
Photo gallery
-
Manufacturer
-
Product Code
BCS-V-EIP58VSR4-AI2
-
Warranty
36 miesięcy
- Technology: IP
- Resolution: 8Mpx
- Enclosure: Dome
- Night visibility: up to 40m
- Connectivity: Wired
- Memory card slot: Yes
- Audio: Yes
- Color: White
Ask about this product show form
Files attached to the product show files
Files for download
-
Size: 0,28 MB
-
Size: 1,43 MB
-
Size: 7,38 MB
Related products
Product Description
Main features:
|
|
8Mpx network dome camera with 2.8-12mm motozoom lens. Compression: H.265 / H.265+ / H.264 / H264+ / MJPEG. 8Mpx resolution, IR illuminator up to 40m, progressive scan, 256GB microSD memory card slot. 1 Audio Input and 1 Audio Output, 1 Alarm Input and 1 Alarm Output. Motion detection, auto tracking, object recognition, perimeter protection, privacy mask, web service. IK10 housing in white, waterproof rating: IP66. Power supply: DC 12V / PoE(802.3af).
Technical specifications:
| Device name | BCS-V-EIP58VSR4-Ai2 |
| Product line | BCS View |
| Camera type | Dome |
| Resolution | 8 Mpx |
| Sensor | 1/1.8'' |
| Scanning system | Progressive Scan |
| Pixels | 3840(H)×2160(V) |
| Lens | motozoom |
| Focal length | 2.8~12 mm |
| Aperture | F 1.4 |
| Focus | Auto / manual |
| Iris | Fixed |
| Optical zoom | 4× |
| Digital zoom | 16× |
| Viewing angle | H: 108°~46° V: 58°~26° D: 127.4°~52° |
| DORI | Detect 86~214m / Observe 34~85m / Recognize 17~43m / Identify 9~21m |
| Sensitivity of the camera | 0.003Lux(F1.4, AGC) 0Lux(B/W,IR) |
| S/N ratio | 52dB |
| White balance | (AWB) Auto / manual |
| WDR | 120dB |
| Backlight compensation | BLC / HLC / WDR(120dB) |
| Shutter | Auto / manual 1/3~1/100000s |
| Gain control | (AGC) Auto / manual |
| Noise reduction | 3D DNR |
| Image rotation | Mirror, Flip 90° |
| Number of streams | 3 |
| Resolutions | 8M(3840×2160) / 6M(3200×1800) / 4M(2688×1520) / 2M(1920×1080) / 720P(1280×720) / VGA(640×480) / 360P(640×360) |
| Main stream | 3840×2160/3200×1800/2688×1520/1920×1080/1280×720(25fps) 3200×1800/2688×1520/1920×1080/1280×720(30fps) |
| Second stream | 640×480/640×360(30fps) |
| Third stream | 1920×1080/1280×720/640×480/640×360(10fps) |
| Bitrate | 32Kbps~16Mbps |
| Video compression | H.265 / H.265+ / H.264 / H.264+ / MJPEG |
| Day/Night | ICR |
| Illuminator type | IR |
| Illuminator | 40m |
| Audio input | 1 |
| Audio output | 1 |
| Audio compression | G.711ulaw / G.711alaw / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC |
| Alarm input | 1 |
| Alarm output | 1 |
| Memory card slot | microSD up to 256GB |
| Support | Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Motion detection | Yes |
| Privacy masks | 4 |
| Networking | RJ-45 10/100 Mbps |
| Compatibility | ONVIF(S/G/T) |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP |
| Power supply type | 12V DC / PoE (802.3af) |
| Power consumption | max 12.5W |
| Housing color | White |
| IP protection class | IP66 |
| IK10 | Yes |
| Operating conditions | -30°C~+60°C max 95% RH |
| Dimensions | Ø135.8×145.5mm |
| Weight | 1 kg |
| Ai - Built-in intelligent functions | Yes |
| Ai - Perimeter protection | Yes |
| Ai - Object recognition | Yes |
| Ai - Face detection | Yes |
