4-in-1 Monitoring Kit 4x HAC-HDW1200TRQ-0280B-S6 2Mpx, IR25m, DWDR, Dahua

Our kits are carefully selected devices that guarantee full compatibility and efficiency. You will find all the necessary components and accessories that will allow you to immediately start installing and configuring your equipment.

The kit includes:

• DH-XVR1B04-I DVR ( 1pc ).
• Camera HAC-HDW1200TRQ-0280B-S6 ( 4pcs ).
• Toshiba S300 1TB hard drive from Surveillance series, dedicated to CCTV solutions ( 1pc ).
• Hard drive 1TB ( 1pc ).
• UTP cat.5e cable ( 20m )
• DC connectors ( 4pcs ), LZ1 connector ( 1pcs ), converters ( 4pcs ).
• Power supply for cameras ( 1 pc )
• Sticker "Attention Object Monitored" ( 1pcs )

Main features:

• Complete monitor kit with 4 cameras HAC-HDW1200TRQ-0280B-S6, DVR and all necessary accessories.
• High quality FullHD image
• Viewing angle of the cameras: 102°
• Outdoor/indoor mountable camera
• Enhanced recording performance with H.265+ codec
• Infrared light range - 25m
• Cameras meeting IP50 waterproof rating
• Hardware DWDR
• 1TB hard drive dedicated for video surveillance systems
• Possibility of remote monitoring via web browser, PC application and mobile device application.
• P2P (cloud) support - a feature that allows remote access without port forwarding and public IP address



High-quality image The light-sensitive sensor and high-quality sensor combined with advanced optics deliver high-quality images with excellent sharpness. The HAC-HDW1200TRQ-0280B-S6 records at 2Mpx resolution, giving it a significant advantage over typical FullHD models. It guarantees that even the smallest detail will be captured on the footage. A: 1280x720p ( 1Mpx ) B: 1920x1080p ( 2Mpx ) C: 2048x1536p ( 3Mpx ) D: 2560x1440p ( 4Mpx ) E: 2560x1960p ( 5Mpx ) F: 3840x2160p ( 8Mpx )

Dome camera HAC-HDW1200TRQ-0280B-S6

• Standards: HD-CVI, HD-TVI, AHD, CVBS.
• Sensor: 2 Mpx CMOS.
• Resolution: 1080p and 960H.
• IR: 25m range, automatic adjustment.
• Lens: 2.8 mm, viewing angle approximately 103°.
• Video output: Multi-format.
• Functions: D-WDR, 3D-DNR, BLC/HLC, ICR, AGC.
• Power supply: 12 V DC, consumption ≤ 2.7 W.
• Enclosure: Dome, plastic, IP50.
• Additional: Operating temperature -40°C to 60°C, weight 0.15 kg.

P2P function

In surveillance cameras is a technology that allows direct communication between the HAC-HDW1200TRQ-0280B-S6 and an end device (such as a smartphone or computer) without the need for an external server. Here are the main features and principles of this function:

• Direct Connection: P2P allows a direct connection between the camera and the user's device. This means that video data can be transmitted directly, without having to go through an intermediary server.
• Ease of Setup: One of the main advantages of P2P is the ease of setup. Users often only need to scan a QR code or enter a camera ID to establish a connection.
• Remote Access: The user can access the camera's video from anywhere in the world, provided both the camera and the end device have Internet access.

Dahua 4 channel DVR DH-XVR1B04-I

• Video inputs: 4x CVI / AHD / TVI / CVBS / IP + 2x IP.
• Video outputs: 1x VGA, 1x HDMI (Full HD)
• Recording (CVI, AHD, TVI): 25/30 fps @ 960x1080 (1080N - 1080p Lite)*.
• Recording (IP): 25/30 fps* @ 3072x2048 (6Mpx)
• Compression format: AI Coding*/H.265+/H.265/H.264+/H.264
• Audio inputs/outputs: 1/1 (RCA)
• Network interface: 1x Ethernet RJ45 100Mbps
• Disk support: 1x Sata III HDD (max. 6TB)
• P2P connection support
• AI functions: SMD+ (4 channels)
• Remote control of camera OSD menus with CoC function
• Audio recording from up to 4 CVI cameras or 10 IP cameras
• Bitrate: 32Kbps ~ 4096Kbps (per channel), 40Mbps - for IP

IP50 weatherproof design Such an enclosure protects the HAC-HDW1200TRQ-0280B-S6 from external factors such as dust, dirt, which is especially important in industrial or dusty environments. Cameras with IP50 housing can be installed in a variety of locations without worrying about environmental damage.

Remote access from your phone and desktop computer Dahua systems allow you to configure, control and view using applications that will provide you with constant access to monitoring from anywhere on earth with internet access. The above programs allow you to: Access video preview and playback of stored footage Save portions of the video to your smartphone's memory Configure time frames for motion detection Receive notifications from motion detection or other events Share your device with other smartphones with the mobile app, such as family members or employees

Wide Dynamic Range - That is, high quality in challenging conditions

The WDR (Wide Dynamic Range) function of the HAC-HDW1200TRQ-0280B-S6 is a technology that improves image quality in difficult lighting conditions, especially when there are very bright and very dark areas in the camera's field of view at the same time. Key aspects of the WDR function are:

• Exposure balancing: WDR helps produce clear images in situations where there is strong backlighting or underexposure, such as when filming from inside a building overlooking a brightly lit exterior.
• Preservation of detail: With WDR, cameras can better capture details in the dark and bright parts of the image. This allows clear recognition of faces, vehicle license plate numbers and other important elements that might not be visible under standard conditions.
• Image processing technology: WDR achieves its effects by quickly switching between different exposure levels or by combining several images taken with different exposure settings to create a single, balanced image.
• Usefulness in security monitoring: This feature is particularly important in security monitoring systems, where it is important to get clear images in a variety of lighting conditions, both indoors and outdoors



Automatic day/night mode Adapted to work in all lighting conditions, the HAC-HDW1200TRQ-0280B-S6 with visibility up to 25m even in total darkness. In addition, the Day/Night sensor switches the video mode automatically based on the amount of light reaching the lens.

For whom will this surveillance kit be suitable?

This is a modern solution with a wide range of applications. Reach for this universal set if you are interested, for example, in monitoring rooms, grounds or objects both indoors and outdoors. It will prove useful wherever you can run a cable installation.

With its help it is possible, among other things:

• monitoring of a store,
• monitoring of a wholesale and warehouse, as well as a production hall,
• monitoring of a school, monitoring of a kindergarten or other educational institutions,
• monitoring of a backyard, sports field or playground,
• monitoring of a private home,
• monitoring of a bar and restaurant,
• monitoring of a parking lot.

Choose this set if you need a professional monitoring system that will not let you down.
