16-channel IP Recorder BCS-P-NVR1602-A-4K-16P(4) - BCS Point
Photo gallery
-
Manufacturer
-
Product Code
BCS-P-NVR1602-A-4K-16P(4)
-
Warranty
36 miesięcy
- Technology: IP
- Number of channels: 16
- Built-in POE switch: Yes
Ask about this product show form
Product Description
Here are the main features of the BCS-P-NVR1602-A-4K-16P(4):
- Product line: BCS Point
- NDAA: National Defense Authorization Act
- System: IP
- Pentaplex function: live viewing / recording / playback / archiving / remote access
- Channels: 16
- Disks: 2
- Disk capacity: 10 TB
- ANR: Automatic synchronization of recordings from camera's microSD card after connection loss and restoration
- Max recording resolution: 16 Mpx
- Input bandwidth: 320 Mbps
- Output bandwidth: 160 Mbps
- Recording resolution: 16M / 12M / 8M / 6M / 5M / 4M / 3M / 2M / 960p / 720p / D1 / 2CIF / CIF
- Video compression: H.265+ / H.265 / H.264+ / H.264
- HDMI output: HDMI 4K
- VGA output: VGA
- HDMI display resolution: 3840×2160 / 1920×1080 / 1600×1200 / 1280×1024 / 1280×720 / 1024×768
- VGA display resolution: 1920×1080 / 1600×1200 / 1280×1024 / 1280×720 / 1024×768
- Output split: 1/4/6/8/9/16 (corridor mode: 3/4/5/7/9/10/12/16)
- Playback: 1/4/9/16
- Archiving: Possibility to rip footage to external media like USB FLASH, USB HDD
- Users: 128
- Interfaces: 1×USB2.0, 1×USB3.0
- Serial port: RS485
- Audio input: 1
- Audio output: 1
- Audio compression: G.711A / G.711U
- Alarm input: 8
- Alarm output: 2
- Support: Local, Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android)
- Network: RJ-45 10/100/1000 Mbps
- Compatibility: ONVIF(S/G/T), support for third-party cameras
- Protocols: TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP
- Standard: IEEE 802.3 af/at
- Switch PoE power: 240W max 30W/port
- PoE channels: 16
- Power supply: 100~240V AC
- Power consumption (without drives): 20W max
- Operating conditions: -10°C~+55°C, max 90% RH
- Enclosure: 1U
- Dimensions (W×D×H): 380×322×53 mm
- Weight (without drives): 2.6 kg
