BCS Point IP Recorder BCS-P-NVR3202-A-4K(4) - 32-channel, HDMI 4K/VGA

Here are the main features of the BCS-P-NVR3202-A-4K(4):

• Product line: BCS Point
• NDAA: National Defense Authorization Act
• System: IP
• Pentaplex function: live viewing / recording / playback / archiving / remote access
• Channels: 32
• Disks: 2
• Disk capacity: 8 TB
• ANR: Automatic synchronization of recordings from camera's microSD card after connection loss and restoration
• Max recording resolution: 16 Mpx
• Input bandwidth: 320 Mbps
• Output bandwidth: 160 Mbps
• Recording resolution: 16M / 12M / 8M / 6M / 5M / 4M / 3M / 2M / 960p / 720p / D1 / 2CIF / CIF
• Video compression: H.265+ / H.265 / H.264+ / H.264
• HDMI output: HDMI 4K
• VGA output: VGA
• HDMI display resolution: 3840×2160 / 1920×1080 / 1600×1200 / 1280×1024 / 1280×720 / 1024×768
• VGA display resolution: 1920×1080 / 1600×1200 / 1280×1024 / 1280×720 / 1024×768
• Output split: 1/4/6/8/9/16/25/32 (corridor mode: 3/4/5/7/9/10/12/16/32)
• Playback: 1/4/9/16
• Archiving: Possibility to rip footage to external media like USB FLASH, USB HDD
• Users: 128
• Interfaces: 2×USB2.0, 1×USB3.0
• Serial port: RS485
• Audio input: 1
• Audio output: 1
• Audio compression: G.711A / G.711U
• Alarm input: 8
• Alarm output: 2
• Support: Local, Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android)
• Network: 2×RJ-45 10/100/1000 Mbps
• Compatibility: ONVIF(S/G/T), support for third-party cameras
• Protocols: TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP
• Power supply: 12V DC
• Power consumption (without drives): 20W max.
• Operating conditions: -10°C~+55°C, max 90% RH
• Enclosure: 1U
• Dimensions (W×D×H): 380×315×53 mm
• Weight (without drives): 2 kg
