Proximity reader Roger PRT66EM-G
Photo gallery
-
Manufacturer
-
Product Code
PRT66EM-G
-
Warranty
36 miesięcy
- Frequency: 125 kHz
- Autonomous operation: No
Ask about this product show form
Files attached to the product show files
Related products
Product Description
PRT66EM-G outdoor proximity reader
The PRT66EM-G proximity reader can operate in terminal or standalone mode, and can be used as a proximity terminal connected to a master access controller or be configured for standalone operation as a simple access controller. The device can be configured for many popular transmission formats, which in practice makes it compatible with most access controllers available on the market. The PRT66EM reader has been designed for use in access control systems based on EM 125 KHz standard proximity tags. The reader in terminal mode operates as a slave device to the access controller and its role is limited to reading the card number and sending the read data to the access controller.
Main features:
- support of EM 125kHz cards (EM4100/4102)
- possibility to attach an additional PRT series reader (two-way passage control)
- output formats: Wiegand 26..66 bit, Magstripe(Clock&Data), RACS(Roger), RS232
- operation in terminal or standalone mode
- two NO/NC inputs
- two transistor outputs
- power supply: 12V DC
- reading range: up to 15 cm
- protection class: IP65
- 120 indexed users
- history: 1024 events
- identification: card
- application: outdoor
- possibility to attach XM-2 type I/O expander
- average current consumption: 45 mA
- tamper protection (tamper)
- separate inputs for LED indicator and speaker control
- possibility to work as EMC-4 card programmer (in cooperation with free RARC software)
- various variants of PIN code transmission
Technical specifications:
| Power supply voltage | Nominal 12VDC, permissible 10-15 VDC |
| Current consumption | 45mA |
| Reading range | Up to 15cm |
| Anti-sabotage protection (Tamper) | NC contact, 50mA/24V |
| Cards | EM 125KHz (compatible with EM4100/4102) |
| Distances | Between reader and controller: max. 150 m Between two PRT readers: max. 150 m Between reader and XM-2 expander: max. 150 m |
| Waterproof class | IP65 |
| Environmental class | IV |
| Operating temperature | -25°C ~ 60°C |
| Humidity | 10% ~ 95% (non-condensing) |
| Weight | 150g |
| Dimensions (W/H/D) | 85x85x27mm |
