Proximity reader Roger MCT12E-IO
Photo gallery
-
Manufacturer
-
Product Code
MCT12E-IO
-
Warranty
36 miesięcy
- Frequency: 125 kHz
- Autonomous operation: No
Ask about this product show form
Files attached to the product show files
Files for download
-
Size: 0,10 MB
-
Size: 0,85 MB
-
Size: 0,30 MB
Related products
Product Description
External proximity reader with keypad MCT12E-IO
MCT12E-IO is an identification terminal designed for use in RACS 5 system. The device enables recognition of users via PIN codes and/or EM125kHz (UNIQUE) standard proximity cards. The MCT12E terminal has an RS485 interface through which it is connected to the communication bus of the MC16 controller. The device can be installed outdoors without additional protection. The MCT12EIO terminal is equipped with three NO/NC inputs, two transistor outputs, one relay output, and has a practical 12-button numeric keypad and two function keys, and allows the operation of an additional PRT series reader. It makes it possible to open the door easily and quickly by entering the corresponding PIN code.
Main features:
- dedicated to RACS5 system
- support for additional PRT series reader
- support for EM 125kHz UNIQUE cards (EM4100/4102)
- operation in terminal mode
- power supply: 12V DC
- read range: up to 7 cm
- communication interface: RS485, RACS CLK/DTA
- waterproof class: IP65
- built-in keypad
- two function keys
- average current consumption: 50 mA
- three LED indicators
- signaling speaker with adjustable sound level
- tamper sensor (Tamper)
- three NO/NC inputs
- two transistor outputs with load capacity 1A/15V
- one relay output with load capacity 1.5A/30V
Technical specifications:
| Supply voltage | Nominal 12VDC, permissible 10-15VDC |
| Current consumption (average) | approx. 50 mA |
| Inputs | Three parametric inputs (IN1..IN3) electrically connected internally to +12V through a 5.6 kΩ resistor. For NO and NC type lines, a trigger threshold of about 3.5V |
| Relay outputs | One relay output (REL1) with one NO/NC contact, load capacity 30V/1.5A DC/AC |
| Transistor outputs | Two transistor outputs (IO1, IO2) open collector type, load capacity 15V/1A DC |
| Tamper protection (TAMPER) | Isolated contacts 50mA/24V, shorted when enclosure closed |
| Cards | EM 125 kHz UNIQUE, compatible with EM4100/4102 |
| Reading range | Up to 7 cm |
| Distances | Up to 1200 m RS485 bus length between controller and reader |
| Protection class | IP65 |
| Operating temperature | -25°C ~ +60°C |
| Humidity | 10% ~ 95% |
| Weight | approx. 150g |
| Dimensions (width/height/length). | Standard stand: 46x152.5x23 Thicker stand: 46x152.5x35mm |
