AHD, HD-CVI, HD-TVI, CVBS, TCP/IP XVR5104HS-I3 4-channel recorder Dahua

A sleek, black digital video recorder with a compact design, featuring multiple connectivity options on the front panel. The device is designed for security systems, supporting various video formats for versatile surveillance solutions.
  • Manufacturer

    Dahua
  • Product Code

    XVR5104HS-I3

  • Warranty

    36 miesięcy

  • Technology: AHD/HD-CVI/HD-TVI/IP
  • Number of channels: 4
  • Built-in POE switch: No

Ask about this product show form

  • Save -40%
  • Availability: in stock Shipping 24h

Price (Incl. VAT):

70,56 € 118 €

Add to Watchlist

Najniższy koszt dostawy: 12,98 zł

Do you represent a budgetary unit?
Check out the deferred payment option.

CA Raty

Product Description

DVR XVR5104HS-I3 with AHD (Analog High Definition), HD-CVI (High Definition Composite Video Interface), HD-TVI (High Definition Transport Video Interface), TCP/IP and CVBS interfaces, is a professional device used in surveillance installations. The menu has been designed to make it easy for any user, even a novice, to navigate and make changes to the DVR settings.


Standard:AHD, HD-CVI, HD-TVI, CVBS, TCP/IP
Video inputs:4 pcs. BNC
Video outputs:1 pcs. HDMI
1 pcs. VGA
Audio inputs:1 pcs. - CINCH
4 - Audio support over coaxial cable, HD-CVI only
Audio outputs:1 pcs. CINCH
Video compression method:AI Coding / H.265+ / H.265 / H.264+ / H. 264
Recorded image resolutions:AHD / HD-CVI / HD-TVI:
5M-N - 1296 x 1440 ,
4M-N - 1280 x 1440 ,
1080p - 1920 x 1080 ,
1080N - 960 x 1080 ,
720p - 1280 x 720 ,


CVBS:
960H - 960 x 576


IP :
max. 6 Mpx - 3072 x 2048
Adjustable recording speed:6 Mpx IP @ 1 ... 25 fps
5M-N @ 1 ... 10 fps
4M-N @ 1 ... 15 fps
1080p @ 1 ... 15 fps
1080N @ 1 ... 25 fps
720p @ 1 ... 25 fps
960H @ 1 ... 25 fps
to be allocated to each channel
Operating modes:4 x AHD / HD-CVI / HD-TVI / CVBS / IP + 2 x IP
Recording modes:Manual, motion detection, schedule
Supported hard drives:1 x 6 TB SATA
Archiving to external media:Snapshot of video frame or archive recordings to USB drive
Search and playback of recordings:Search for recordings by time + time line with recording type. Playback: forward, accelerate, decelerate, stepwise
Advanced search (every second)

Intelligent AI face search - simultaneous search in the archive of face recordings based on up to 8 images with consideration of similarity threshold (for each image separately)
Synchronous 1/4 channel split playback
Network functions:Full network support, Remote copy of recordings, Built-in web server max. 128 users online
Cell phone access:Port: 37777 or access via cloud (P2P)
  • Android: Free DMSS app
  • iOS (iPhone): Free DMSS app

    See the video on how to set up P2P on Dahua DVRs and how to enable the mobile app
Alarm inputs/outputs:No
PTZ control:IP Speed Dome cameras
HD-CVI coax PTZ compatible control
RS-485 - PELCO-D/P
Motion detection:Screen zoning : 22 x 18 detection fields
Selected features:
  • Cooperation with Dahua-branded devices working with the Internet of Things (IoT) concept,
  • POS - cooperation with devices installed in points of sale and displaying data from them in the form of superimposed text in the selected channel window,
  • SMD PLUS - search for an object classified as: human, motor vehicle
  • Coax Audio/Alarm support,
  • Intelligent Image Analysis : line crossing, trespassing, classification of people and vehicles
  • Advanced face recognition and search functions
  • Support for up to 10 face databases, with a total of 10,000 face images
  • Detection of faces not in the device's database
  • Searching for faces in recordings based on up to 8 selected images, with the ability to independently set the similarity threshold for each image
USB:2 pcs. USB 2.0
Mouse operation:Yes
IR remote control included:No
Power supply:12 V DC / 1.5 A (power adapter included)
Color:Black
Weight:0.87 kg
Dimensions:260 x 236 x 48 mm
Supported languages:Polish, English, Czech, Danish, Finnish, French, Greek, Spanish, Dutch, German, Portuguese, Russian, Romanian, Serbian, Slovak, Slovenian, Hungarian, Italian
Manufacturer/Brand:Dahua

Szczegóły dotyczące zgodności produktu z przepisami: Osoba odpowiedzialna za produkt
