Carbon monoxide sensor FireAngel FA3820-INT

The image shows a sleek, white carbon monoxide alarm with a circular test button and indicator lights, designed for a 10-year lifespan. The packaging highlights its certifications and features, emphasizing safety and reliability.
A sleek, white carbon monoxide and smoke detector with a circular sensor and test button on the left side. The device features clear icons indicating its functions and a small vent on the right for air intake.
A sleek, white carbon monoxide and smoke detector with a circular sensor area and clearly marked test button. The device features icons indicating its dual functionality for detecting both smoke and carbon monoxide.
Side view of a sleek, white smoke and carbon monoxide detector with a modern, curved design. The device features ventilation slots and a small circular sensor on its surface.
A sleek carbon monoxide and smoke alarm with a modern design is displayed on a kitchen countertop, featuring easy-to-read buttons and indicators. The packaging and user manual are also visible, emphasizing its user-friendly setup and functionality.
A sleek, modern smoke and carbon monoxide detector is mounted on a stylish, muted green wall above a contemporary gray sofa. The living room setting highlights the detector's compact design and seamless integration into home decor.
A compact smoke and carbon monoxide detector is placed on a bedside table next to a modern lamp and a patterned mug. The device features a sleek design with a circular button and indicator lights, blending seamlessly into the cozy bedroom setting.
Illustration of a house interior highlighting recommended placements for smoke and carbon monoxide detectors. The image includes labeled areas for each detector type, with a focus on safety in various rooms.
Diagram of a smoke and carbon monoxide detector showing side and top views with dimensions. The device features a sleek, oval design with a central sensor and a small indicator light.

  • Manufacturer

    FireAngel

  • Product Code

    FA3820-INT

  • Warranty

    10 lat

  • Sensor type: Carbon Monoxide

see description

Ask about this product show form

Do you have questions? Looking for answers? Are you interested?

  • Call
  • 34 341 16 30
  • We advise Mon - Fri 8 00 am to 4 00 pm
  • or send a message using the form below

Copy the code from the picture

weryfikator

Close

Files attached to the product show files

Files for download

Close

  • Save -22%
  • Availability: in stock Shipping 24h

Price (Incl. VAT):

37,76 € 48,14 €

Add to Watchlist

Najniższy koszt dostawy: 12,98 zł

Do you represent a budgetary unit?
Check out the deferred payment option.

CA Raty

Product Description


Product features:

  • sensor type: electrochemical
  • 85dB sound signal within 3m radius
  • intelligent detection algorithm- increases the speed of response when low CO level is detected
  • sensor test/reset function
  • signaling: acoustic and optical
  • low battery and end of operation signaling
  • mounting: wall-mounted, free-standing
  • modern self-monitoring system with the possibility of data reading
  • memory function - signaling earlier alarm activation
  • power supply: built-in lithium battery (life span of 10 years)
  • certificate of compliance with EN50291-1:2018, EN50291-2:2019, PN-EN50291-1:2018+AC:2021 standards
  • working temperature -10°C to +40°C
  • working humidity 30% ~ 90% RH
  • weight: 95g
  • dimensions: 125x67x33mm (W/H/D)
  • warranty: 10 years



The FireAngel FA3820 sensor is a high-end device for protection against carbon monoxide poisoning. The FA3820's unique design ensures quick response even when detecting trace amounts of carbon monoxide in the air. The detector has a 10-year built-in lithium battery, which does not need to be replaced throughout its lifetime. If a threat is detected, the detector will warn with a clear visual indication and a loud 85 dB alarm. One of the most important features of the device is a unique technology that allows to increase the sensitivity of the sensor when a small amount of carbon monoxide is detected. The reliability and high quality of the device is confirmed by the BSI certificate of compliance with EN50291-1:2018 and EN50291-2:2019. The FA3820 sensor also meets the requirements for the latest building products regulations and has the Safety Mark B. The device comes with a 10-year warranty and service life.







Sensor arrangement


A carbon monoxide (chad) sensor should be installed in each room where there is a fuel-burning appliance (boiler room, bathroom, living room, etc.). Installation of additional sensors is recommended in rooms where users spend a lot of time (such as the bedroom or living room)






Installation of the sensor


Wall mounting: use the template included in the box for guidance on the location of mounting holes. Drill holes in the wall and insert plastic wall plugs. Screw in the screws so that they protrude from the wall by 3 mm. Hang the sensor on the special mounting holes. The base of the sensor is designed so that the device can stand freely on the shelf.





Product demonstration video


The FA3820-INT sensor uses an electrochemical sensor to measure the concentration of carbon monoxide in the air. It is factory calibrated and requires no maintenance by the user. If a threat is detected, the sensor can send an alarm signal to a building management system or warning device.




Detailed technical specifications:


Dimensions 125 mm (width) x 67 mm (height) x 33 mm (depth)
Power supply voltage 3V DC
Power supply 10-year built-in lifetime lithium battery
Sensor Electrochemical
Alarm volume 85dB(A) at 3m (minimum)
Mounting method Wall mounted/free standing (Portable - suitable for home and/or travel use)
For use Domestic premises, including stationary and mobile, campers, caravans and boats*
Operating temperature -10°C to +40°C
Operating humidity 30 - 90% RH
Storage temperature -20°C to +50°C
Storage humidity 30 - 90% RH (non-condensing)
Plastic Fire-resistant ABS
Warranty 10 years
Certifications BSI EN 50291-1:2018, EN 50291-2:2019 , CNBOP-PIB Certificate PN-EN 50291-1:2018+AC:2021
Independently tested by BSI (certificate number KM 551504)
Weight 95g
EAN code 0816317006037
