IP Camera BCS-L-TIP58VSR6-Ai1-G(2) tubular 8 Mpx, 1/1.8" motorized zoom 2.7 ... 12mm sensor
Photo gallery
-
Manufacturer
-
Product Code
BCS-L-TIP58VSR6-AI1-G(2)
-
Warranty
36 miesięcy
- Technology: IP
- Resolution: 8Mpx
- Enclosure: Tube
- Night visibility: up to 60 m
- Memory card slot: Yes
- Audio: Yes
- Color: Black
Ask about this product show form
Files attached to the product show files
Product Description
Main features:
|
|
This advanced device is an 8 Mpx horn camera offering 4x optical zoom and 16x digital zoom. Its wide viewing angle and advanced AI features, such as object recognition and perimeter protection, provide comprehensive monitoring capabilities. The camera also features high sensitivity in low-light conditions and is weatherproof (IP67) and mechanically rugged (IK10).
Technical specifications:
| Device Name | BCS-L-TIP58VSR6-Ai1-G(2) |
| Product line | BCS Line |
| Camera type | Tube |
| Resolution | 8 Mpx |
| Sensor | 1/1.8'' |
| Scanning system | Progressive Scan |
| Pixels | 3840(H)×2160(V) |
| RAM | 1GB |
| ROM | 128MB |
| Lens | motozoom |
| Focal length | 2.7~12 mm |
| Aperture | F1.6 |
| Focus | Auto / manual |
| Iris | Auto |
| Optical zoom | 4× |
| Digital zoom | 16× |
| Viewing angle | H: 113°~47° V: 60°~26° D: 133°~53° |
| DORI | Detect 83~190m / Observe 33~76m / Recognize 17~38m / Identify 8~19m |
| Camera sensitivity | 0.003Lux(F1.6,30IRE) 0.0005Lux(F1.6,B/W,30IRE) 0Lux(IR) |
| S/N ratio | 56dB |
| White balance | (AWB) Auto / manual |
| WDR | 120dB |
| Backlight compensation | BLC / HLC / WDR(120dB) / SSA |
| Shutter | Auto / manual 1/3~1/100000s |
| Gain control | (AGC) Auto / manual |
| Noise reduction | 3D DNR |
| Image Stabilization | Electronic (EIS) |
| Defog | Electronic |
| Image Rotation | Mirror, Flip 0°/90°/180°/270° |
| Number of streams | 3 |
| Resolutions | 8M(3840×2160) / 6M(3072×2048) / 5M(3072×1728)(2592×1944) / 4M(2688×1520)(2560×1440) / 3M(2048×1536)(2304×1296) / 2M(1920×1080) / 1.3M(1280×960) / 720P(1280×720) / D1(704×576/704× 480) / VGA(640×480) / CIF(352×288/352×240) |
| Main stream | 3840×2160(1~25/30fps) |
| Second stream | 704×576(1~25fps) 704×480(1~30fps) |
| Third stream | 1920×1080(1~25/30fps) |
| Bitrate | H.264: 3 kbps~16384 kbps H.265: 3 kbps~16384 kbps |
| Video compression | H.265+ / H.265 / H.264+ / H.264 / MJPEG / Ai Coding |
| Day/Night | ICR |
| Illuminator type | IR |
| Illuminator | 60m |
| Microphone | Yes |
| Audio input | 1 |
| Audio output | 1 |
| Audio compression | G.711A / G.711Mu / G.723 / G.726 / PCM |
| Alarm input | 1 |
| Alarm output | 1 |
| Memory card slot | microSD 256GB |
| Support | Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Motion detection | 4 |
| Privacy masks | 4 |
| Networking | RJ-45 10/100 Mbps |
| Compatibility | ONVIF(S/G/T) |
| Protocols | IPv4, IPv6, HTTP,TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, SNMP, P2P |
| Power supply type | 12VDC / PoE(802.3af) |
| Power consumption | max 10.5W |
| Housing color | Graphite |
| IP protection class | IP67 |
| Operating conditions | -30°C~+60°C max 95% RH |
| Dimensions | 244.1×79×75.9mm |
| Weight | 0.8 kg |
| Ai - Built-in intelligent functions | Built-in intelligent image recognition and analysis algorithms |
| Ai - Perimeter protection | Intrusion into the area, crossing the line |
| Ai - Object recognition | Person/vehicle recognition for area intrusion, line crossing reduces false alarm triggering. |
| Ai - SMD | SMD 4.0 |
