4-in-1 TVICAM-T2M-20DL Full HD HiLook by Hikvision Camera
Photo gallery
-
Manufacturer
-
Product Code
TVICAM-T2M-20DL
-
Warranty
24 miesiące
- Technology: AHD/HD-CVI/HD-TVI
- Resolution: 2Mpx
- Enclosure: Dome
- Night visibility: up to 20m
- Connectivity: Wired
- Memory card slot: No
- Audio: No
- Color: White
Ask about this product show form
Related products
Product Description
Contents of the TVICAM-T2MDL package:
In addition to the camera, the box also contains useful instructions and mounting accessories to speed up the entire process of mounting the camera.
- 1x 2Mpx dome camera - HiLook by Hikvision TVICAM-T2M-20DL.
- Documentation - User manual, warranty card, adjustments
- Template - Small size template with camera mounting holes
- Screws and mounting studs - Everything you need to mount the camera
- Waterproof kit - A set of accessories to protect the camera's connectors from moisture
HiLook by Hikvision products are all about ease of use, literally anyone can handle the installation and setup thanks to the included instructions.
Features of the TVICAM-T2M-20DL camera:
- High-quality imaging with 2 Mpx, 1920 x 1080 resolution.
- 2.8mm fixed focus lens
- Infrared light range up to 20 meters
- White light range up to 20 meters
- Supports four analog TVI/AHD/CVI/CVBS systems
- IP66 water and dust resistance
- Smart Hybrid-Light
High-quality imageThe light-sensitive sensor in the TVICAM-T2M-20DL camera and a high-quality sensor combined with advanced optics deliver high-quality images with excellent sharpness. The device records at 2Mpx resolution, giving it a significant advantage over typical FullHD models. It guarantees that even the smallest detail will be captured on the footage.
|
 |
Motion detectionTVICAM-T2M-20DL has a built-in algorithm for detecting motion in images. In addition, it allows you to send notifications to your phone or computer. In addition, you can freely set the area you are interested in, so that, for example: you can receive notifications only for motion from the entrance gate. In addition to recording 24/7, the cameras can also record only fragments when motion is detected, which will translate into lower hard drive consumption. |
 |
IP66 weatherproof design
This housing protects the TVICAM-T2M-20DL from external factors such as dust, dirt and moisture, which is especially important in industrial environments or dusty areas. Cameras with IP66 housing can be installed in a variety of locations, from industrial to marine, without worrying about environmental damage. |
 |
Wide dynamic range - That is, high quality in difficult conditions
The WDR (Wide Dynamic Range) function of the TVICAM-T2M-20DL is a technology that improves image quality in difficult lighting conditions, especially when there are very bright and very dark areas in the camera's field of view at the same time. Key aspects of the WDR function are:
- Exposure balancing: WDR helps produce clear images in situations where there is strong backlighting or underexposure, such as when filming from inside a building overlooking a brightly lit exterior.
- Preservation of detail: With WDR, cameras can better capture details in the dark and bright parts of the image. This allows clear recognition of faces, vehicle license plate numbers and other important elements that might not be visible under standard conditions.
- Image processing technology: WDR achieves its effects by quickly switching between different exposure levels or by combining several images taken with different exposure settings to create a single, balanced image.
- Usefulness in security monitoring: This feature is particularly important in security monitoring systems, where it is important to get clear images in a wide variety of lighting conditions, both indoors and outdoors.
Automatic day/night modeAdapted to work in all lighting conditions, TVICAM-T2M-20DL with visibility up to 20m even in total darkness. In addition, the Day/Night sensor switches the video mode automatically based on the amount of light reaching the lens. |
 |
Technical specifications of TVICAM-T2M-20DL:
| Camera | |
| Image sensor | 2 MP CMOS |
| Max resolution | 1920 (S) × 1080 (W) |
| Minimum illumination | 0.02 lux @ (F1.2, AGC ON), 0 lux with IR |
| Shutter time | PAL: 1/25 s to 1/50,000 s, NTSC: 1/30 s to 1/50,000 s |
| Day/Night | ICR |
| Angle adjustment | Pan: 0 to 360°, Tilt: 0 to 75°, Rotation: 0 to 360° |
| Signal system | PAL/NTSC |
| Lens | |
| Lens type | 2.8mm fixed focal length |
| Focal length and FOV | 2.8 mm, horizontal FOV: 97°, vertical FOV: 54°, diagonal FOV: 113° |
| Lens mount | M12 |
| Illumination | |
| Type of supplementary light | White light, Infrared |
| Range of supplementary light | Infrared: Up to 20 m, White light: Up to 20 m |
| Image | |
| Image parameter switch | STD/HIGH-SAT/HIGHLIGHT |
| Image settings | Brightness, sharpness, Smart IR |
| Frame rate | TVI: 1080p @ 30 fps, 1080p @ 25 fps |
| AHD: 1080p @ 30 fps, 1080p @ 25 fps | |
| CVI: 1080p @ 30 fps, 1080p @ 25 fps | |
| CVBS: PAL/NTSC | |
| Wide Dynamic Range (WDR) | Digital WDR |
| Image enhancement | DWDR/BLC/HLC/Global |
| White balance | Auto/Manual |
| AGC | Yes |
| Interface | |
| Video output | Switchable TVI/AHD/CVI/CVBS |
| General | |
| Material | Metal |
| Dimensions | 90 mm × 82.6 mm × 81.1 mm (3.5'' × 3.3'' × 3.2'') |
| Weight | Max. 290 g (0.64 lb.) |
| Operating conditions | -40 °C to 60 °C, humidity: 90% or less (non-condensing) |
| Communication | Hik-Connect, HiLookVision |
| Language | Polish |
| Power supply | 12 VDC ± 25%, Max. 2.9 W |
| *It is recommended to use one power supply to power one camera. | |
| Protection | IP66 |
